Highclere Medical Centre
Portsmouth
Link was appointed by the Solent NHS trust to support the construction of the North Harbour Medical Centre. Our role included delivering a detailed Section 278 (S278) design and securing technical approval for the egress, along with amendments to the existing footway and bus stop.
As part of the project, we also designed and obtained approval for modifications to Northern Road, London Road, and St George’s Road to improve the northbound right-turn facility. This involved creating a ghost right-turn junction and widening the carriageway.
Do you have any highway schemes that require assistance? Please get in touch to discuss how Link can assist you.
The scope of works included:
- Horizontal and vertical access design for the priority access and egress off Northern Road, detailing the key geometric constraints and requirements in accordance with CD 123 Geometric design of at-grade priority and signal-controlled junctions of Design Manual for Roads and Bridges (DMRB) and LHA Local Standards;
- Horizontal and vertical access design for the Ghost Right at Northern Road / London Road / St Georges Road junction, detailing the key geometric constraints and requirements in accordance with CD 123 Geometric design of at-grade priority and signal-controlled junctions of Design Manual for Roads and Bridges (DMRB) and LHA Local Standards;
- Long/cross sections through the proposed access and existing modifications;
- Carriageway / Footway / cycleway detailed pavement design to LHA specification
- Street Lighting design at Northern Road / London Road / St Georges Road junction;
- Swept path analysis to support detailed design;
- C3 / C4 estimate;
- Site clearance drawing for existing features to support detailed design;
- Highway drainage design/amendments to existing drainage as required
- Hydraulic Calculations for drainage as necessary;
- Kerbing and edgings;
- Carriageway Markings;
- Signing design of warning and regulatory signage to support TRO.
- Traffic Regulation Orders;
- Liaison with the adopting authorities;
- Liaison with the client/design team;
- Designers response to Stages 1, 2 & 3 Road Safety Audit (RSA),
- Highway setting out in 3D string format;
- All required construction drawings and details;
- Provision of legal coloured plans for adoption agreement purposes;
- Completion of designer’s risk assessments;
- Provision of all design drawings in AutoCAD 2018 and PDF format. No provision for hard copy drawings has been allowed.
